NEW FrSky Tandem X18 Transmitter
| Part No.: | TD-X18-BK |
| Manufacturer: | Frsky |
Send to a friend
Features
Hardware
* Enhanced ergonomic designed case with comfortable rounded hand grips
* 4 Standard Trims with additional 2 extra trims
* Integrate flash storage but also keep the internal TF card slot
* Easy-to-reach top switches and sliders
* With a flat base to improve stability when standing the radio
* Color Touch-Screen Displays
* High-Precision Hall-Sensor Gimbals with a Metal Panel
* 6 Quick-Mode Custom Buttons (Front) and 2 Momentary Buttons (Rear)
* Lite Type External Module Bay
* Haptic Vibration Alerts and Voice Speech Outputs
* Supports Recharge System for 2S Li-ion Battery (USB Type-C Interface)
* High-speed PARA Wireless Training System
TD-ISRM RF Module
* Built-in TD 900M/2.4G Dual-Band Internal RF Module Supports Multiple Working Modes
- 2.4G ACCST D16 Mode (Compatible with ACCST Receivers with D16 V2 or later FW)
- 2.4GACCESS Mode (Compatible with ACCESS Receivers)*
- 900M ACCESS Mode (Compatible with ACCESS R9 868/915MHz Receivers)*
(*Capable of simultaneous working under ACCESS mode)
- 2.4G & 900M TD Mode (Compatible with TD Receivers)
* Long-range control and super-low latency with telemetry
(*Up to 50 to 100KM range and down to 4ms end-to-end latency)
ETHOS System
* Clear and Intuitive UI Design
* Supports Dual Operation Modes of Radio Display (Touch and Non-Touch)
* Supports Multi-Language Switching
* Hardware/Software Version and Factory Version Detection
* Supports running LUA Scripts
* Enhanced ergonomic designed case with comfortable rounded hand grips
* 4 Standard Trims with additional 2 extra trims
* Integrate flash storage but also keep the internal TF card slot
* Easy-to-reach top switches and sliders
* With a flat base to improve stability when standing the radio
* Color Touch-Screen Displays
* High-Precision Hall-Sensor Gimbals with a Metal Panel
* 6 Quick-Mode Custom Buttons (Front) and 2 Momentary Buttons (Rear)
* Lite Type External Module Bay
* Haptic Vibration Alerts and Voice Speech Outputs
* Supports Recharge System for 2S Li-ion Battery (USB Type-C Interface)
* High-speed PARA Wireless Training System
TD-ISRM RF Module
* Built-in TD 900M/2.4G Dual-Band Internal RF Module Supports Multiple Working Modes
- 2.4G ACCST D16 Mode (Compatible with ACCST Receivers with D16 V2 or later FW)
- 2.4GACCESS Mode (Compatible with ACCESS Receivers)*
- 900M ACCESS Mode (Compatible with ACCESS R9 868/915MHz Receivers)*
(*Capable of simultaneous working under ACCESS mode)
- 2.4G & 900M TD Mode (Compatible with TD Receivers)
* Long-range control and super-low latency with telemetry
(*Up to 50 to 100KM range and down to 4ms end-to-end latency)
ETHOS System
* Clear and Intuitive UI Design
* Supports Dual Operation Modes of Radio Display (Touch and Non-Touch)
* Supports Multi-Language Switching
* Hardware/Software Version and Factory Version Detection
* Supports running LUA Scripts
Product Details
Dimension: 200*192*95mm (L*W*H)
Weight: 687g (Battery Excl.) / 820g (Battery Incl.)
Operating System: ETHOS
Internal RF Module: TD-ISRM
Number of Channels: Up to 24 channels
Operating Voltage Range: 6.5 ~ 8.4V (2S Li-battery)
Operating Temperature: -10°C~60°C (14°F~140°F)
Operating Current: 240mA@7.4V (typ.)
Charging Current: ≤1A ±200mA
USB Adaptor Voltage: 5V+0.2V
USB Adaptor Current: >2.0A
Backlit touchable LCD resolution: 480*320
Compatibility: ACCST D16 & ACCESS & TD receivers
Weight: 687g (Battery Excl.) / 820g (Battery Incl.)
Operating System: ETHOS
Internal RF Module: TD-ISRM
Number of Channels: Up to 24 channels
Operating Voltage Range: 6.5 ~ 8.4V (2S Li-battery)
Operating Temperature: -10°C~60°C (14°F~140°F)
Operating Current: 240mA@7.4V (typ.)
Charging Current: ≤1A ±200mA
USB Adaptor Voltage: 5V+0.2V
USB Adaptor Current: >2.0A
Backlit touchable LCD resolution: 480*320
Compatibility: ACCST D16 & ACCESS & TD receivers
Item Packing
Tandem X18 Transmitter x 1
