Holybro FETtec Mini AIO 15A 2-4S ESC Module For FPV Cinewhoop Drone Parts
| Part No.: | HL-MINI15A |
| Manufacturer: | Holybro |
Send to a friend
Features
FC:
KISS FC firmware
F3 Processor (STM32F303CCT6 @ 72MHz (MPU6000))
Supply voltage 6-18V (2S-4S Lipo voltage)
Dedicated onboard 5V BEC (max 1A)
ESC:
Active current limiting @ 15A
Input voltage: 2S-4S
High quality 30V MOSFETs
• STM32G071 @ 64MHz
128 kHz Motor PWM
Automatic input signal detection
Dshot 300-2400
PWM
OneShot42/125
OSD:
Graphic OSD (STM32)
Full KISS Tuning
Filter (PIDs, Rates, Settings)
LED control (RGB LED, Racewire)
VTX
Live data graphs (Voltage, motor rpm, current, motor temp, gyro values, link quality)
KISS GPS support + live map
Custom graphic pilot logo
Stick overlay
Custom layout
The FETtec Mini AIO 15A works with KISS/FETtec FC firmware version 1.3RC45Y or later !
Product Details
Size: 29 x 29 mm
Mounting: 25,5 x 25,5 mm
Weight: 3.6 g
Safety warning: Remove propellers before flashing and configuration
Item Packing
FC board x 1
M2 Anti-Vibration Silicone Grommet Insert x 4
M2 Anti-Vibration Silicone Grommet Insert x 4
Detailed Images
