HOBBYWING XERUN V10 G4 21.5T 2500KV Sensored Brushless Motor For RC Car 1/10th STOCK Class Racing

HOBBYWING XERUN V10 G4 21.5T 2500KV Sensored Brushless Motor For RC Car 1/10th STOCK Class Racing
Part No.: V10-G4-21.5T
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

Built for the ultra-competitive Stock racing category around the world, the XeRun V10 G4 motor has all the winning formula you need to win a race. The V10 G4 motor has been tested and developed intensively by our factory drivers such as Spencer Rivkin, Jan Ratheisky and Max Machler to give the ultimate performance.
The new generation of the V1O G4 motor is greatly optimized.The stator is redesigned for higher efficiency and is equipped with an ultra-high grade custom magnetic ring rotor to provide maximum torque output and an increase in output power by 5%

The motor adopts a fully exposed stator core and is directly exposed to the airfor excellent heat dissipation. The outer diameter is maximized to increases thestator heat dissipation area by 25.6% compared to the v10 G3R motor.

The motor is equipped with a high-precision endbell plate.lt uses high quality structural components to greatly improves the consistency and structural stability of thepower output at all times.

The motor adopts modular structural design, which is convenient for daily maintenance.This effectively prolongs the service life of the motor and maintains the efficiency of the motor.

Product Details

Product Name: XERUN V10-G4-21.5T
Product Number: 30401142
Type
- Scale: 1/10th
- Brushed/Brushless: BL
- Sensored/Sensorless: SD
- Pole Count: 2
Relevant Parameters
- KV Rating: 2500KV
- LiPo Cells: 2-3S
- No-load Current(A): 3.0A
Size & Weight
- O.D.(mm): 35.8
- Length (mm): 51.4
- Shaft Diameter (mm): 3.175
- Weight (g): 148g
- Front Bearing: D9*D4*t4
- Rear Bearing: D8*D3*t4
Other Parameters
- Timing: 30-60 Degrees(Adjustable)
- Applications: 1/10th STOCK Class Racing

Item Packing

21.5T 2500KV Sensored Brushless Motor x 1

Detailed Images
