Tarot Z25 folding arm seat / matte black TL25A1
| Part No.: | TL25A1 |
| Manufacturer: | TAROT |
Send to a friend
Features
Tarot Z25 folding arm seat / matte black TL25A1
Product Details
Applicable to the diameter Φ25MM four-axis / six-axis / eight-axis multi-rotor unmanned aerial vehicle use, the use of button-type unlock, a key to unlock the automatic folding, easy to use simple, retractable. Locking mechanism can be based on the arm vibration, automatic one-way lock function.
In line with the needs of industrial-grade unmanned aerial vehicles, the overall use of 6061-T6 aluminum alloy super-hard aluminum alloy material, high-precision multi-axis CNC machining. X4 Ⅱ / X6 Ⅱ / X8 Ⅱ and other models can be installed directly.
Related Product Code:
Z25 folding arm seat / matte black TL25A1
T25 folding arm seat / 6 degrees tilt TL25A2
Z28 waterproof folding arm seat / matte black TL28A1
T28 waterproof folding arm seat / 6 degrees tilt TL28A2
Z30 waterproof folding arm seat / matte black TL30A1
Z28 / Z30 metal connection plate TL28A3
In line with the needs of industrial-grade unmanned aerial vehicles, the overall use of 6061-T6 aluminum alloy super-hard aluminum alloy material, high-precision multi-axis CNC machining. X4 Ⅱ / X6 Ⅱ / X8 Ⅱ and other models can be installed directly.
Related Product Code:
Z25 folding arm seat / matte black TL25A1
T25 folding arm seat / 6 degrees tilt TL25A2
Z28 waterproof folding arm seat / matte black TL28A1
T28 waterproof folding arm seat / 6 degrees tilt TL28A2
Z30 waterproof folding arm seat / matte black TL30A1
Z28 / Z30 metal connection plate TL28A3
Item Packing
Metal left support plate × 1 (54.5 × 40 × 5.5MM) 15.0G
Metal right support plate × 1 (54.5 × 40 × 5.5MM) 15.0G
M3.0 × 5MM step hexagon screw × 8
M2.5 × 5MM cup head hexagonal screws × 4
Φ4 × 26MM spring × 2
H5 × 22.5MM hexagonal aluminum column × 2
M2.5 × 5MM semi-circular hexagonal screws × 2
Unlock the slider × 1 (66 × 16 × 21.5MM) 6.2G
Self - locking copper pillar × 1 (Φ6 × 27MM) 5.8G
Φ25MM metal machine arm clamp × 1 (58 × 30 × 35MM) 24.8G
Φ6 × 28.5MM Locating pin × 1 (Φ7 × 37.5MM) 6.1G
M3.0 × 6MM round head with hex head screws × 1
M3 metal gasket × 1
Metal right support plate × 1 (54.5 × 40 × 5.5MM) 15.0G
M3.0 × 5MM step hexagon screw × 8
M2.5 × 5MM cup head hexagonal screws × 4
Φ4 × 26MM spring × 2
H5 × 22.5MM hexagonal aluminum column × 2
M2.5 × 5MM semi-circular hexagonal screws × 2
Unlock the slider × 1 (66 × 16 × 21.5MM) 6.2G
Self - locking copper pillar × 1 (Φ6 × 27MM) 5.8G
Φ25MM metal machine arm clamp × 1 (58 × 30 × 35MM) 24.8G
Φ6 × 28.5MM Locating pin × 1 (Φ7 × 37.5MM) 6.1G
M3.0 × 6MM round head with hex head screws × 1
M3 metal gasket × 1
Detailed Images
