T-MOTOR CINE66 2812 1155KV 4-6S Brushless Motor for RC Airplane Multirotor X-Class Cinelifter FPV Drones
| Part No.: | Cine66-1155KV |
| Manufacturer: | T-MOTOR |
Send to a friend
Features
T-MOTOR CINE66 2812 1155KV 4-6S Brushless Motor for RC Airplane Multirotor X-Class Cinelifter FPV Drones
Product Details
Kv: 1155Kv
Input Voltage: 4-6S LiPo
Configuration: 12N14P
Max Continuous Current: 54.5A
Internal Resistance: 47mΩ
Motor Dimensions: Φ34.4mm x 39.9mm
Stator Dimensions: Φ28mm x 12mm
Shaft Diameter: 5mm
Mounting Pattern: Φ19mm
Wire Dimensions: 18AWG x 250mm
Weight (w/ wires): 76.5g
Input Voltage: 4-6S LiPo
Configuration: 12N14P
Max Continuous Current: 54.5A
Internal Resistance: 47mΩ
Motor Dimensions: Φ34.4mm x 39.9mm
Stator Dimensions: Φ28mm x 12mm
Shaft Diameter: 5mm
Mounting Pattern: Φ19mm
Wire Dimensions: 18AWG x 250mm
Weight (w/ wires): 76.5g
Item Packing
Motor x 1
Parts Bag x 1
Parts Bag x 1
Detailed Images
