Electric-Miscellaneous > Product details
FEELWORLD LIVEPRO L1 Multi-format Video Mixer Switcher inputs multi camera production USB3.0 live streaming Youtube
| Part No.: | LIVEPRO-L1 |
| Manufacturer: | Feixiang |
Send to a friend
Features
LIVEPRO L1 with 4 CH HDMI inputs and 1 HDMI output, all of them support 1080p. For live streaming, there is a USB3.0 interface And plus, the LAN port for controlling and upgrading; for audio, it has 2 interfaces, one for input, and the other one for output. All of these make it easy to create professional multi camera productions. It is able stream any one from the 4 HDMI inputs to any live broadcasting platform via third party live streaming software such as OBS. Simply connect LIVEPRO L1 and you can switch live between 4 high quality video camera inputs for dramatically better quality images. Or connect a computer for PowerPoint slides or gaming consoles.
Product Details
Panel characteristics
Model: livepro L1
Screen size: 2.0 "TFT screen
Backlight: LED
input
4 X HDMI：HDMI
output
1 X HDMI：HDMI
1×USB Type A：USB3.0
audio frequency
Audio input: 1 × 3.5mm audio socket
Audio output: 1 × 3.5mm audio socket
Input resolution
HDMI
SMPTE 720p@50/60 | 1080i@50 | 1080p@23/24/30/50/60
VESA 1024× 768@60 | 1280× 720@60 |1280× 768@60 |1280× 800@60 | 1280× 1024@60 | 1360× 768@60 | 1366× 768@60 | 1440× 900@60 | 1600× 1200@60 | 1680× 1050@60 | 1920x1080@50i | 1920× 1080@60 | 1920x1080@60i |1920× 1200@60
Output resolution
HDMI
SMPTE 720p@60 | 1080p@60
VESA 1024× 768@60 | 1280× 720@60 |1280× 768@60 |1280× 800@60 | 1280× 1024@60 | 1360× 768@60 | 1366× 768@60 | 1440× 900@60 | 1680× 1050@60 | 1920× 1080@60
Other specifications
Maximum power: 18W
Working temperature: - 30 ℃ ~ 50 ℃
Working humidity: 10% ~ 85%
Single machine size: 185 (L) x 110 (W) x 39 (H) mm
Unit weight: 648g
Model: livepro L1
Screen size: 2.0 "TFT screen
Backlight: LED
input
4 X HDMI：HDMI
output
1 X HDMI：HDMI
1×USB Type A：USB3.0
audio frequency
Audio input: 1 × 3.5mm audio socket
Audio output: 1 × 3.5mm audio socket
Input resolution
HDMI
SMPTE 720p@50/60 | 1080i@50 | 1080p@23/24/30/50/60
VESA 1024× 768@60 | 1280× 720@60 |1280× 768@60 |1280× 800@60 | 1280× 1024@60 | 1360× 768@60 | 1366× 768@60 | 1440× 900@60 | 1600× 1200@60 | 1680× 1050@60 | 1920x1080@50i | 1920× 1080@60 | 1920x1080@60i |1920× 1200@60
Output resolution
HDMI
SMPTE 720p@60 | 1080p@60
VESA 1024× 768@60 | 1280× 720@60 |1280× 768@60 |1280× 800@60 | 1280× 1024@60 | 1360× 768@60 | 1366× 768@60 | 1440× 900@60 | 1680× 1050@60 | 1920× 1080@60
Other specifications
Maximum power: 18W
Working temperature: - 30 ℃ ~ 50 ℃
Working humidity: 10% ~ 85%
Single machine size: 185 (L) x 110 (W) x 39 (H) mm
Unit weight: 648g
Item Packing
1 × LIVEPRO L1 Video Switcher
1 × 12V / 1.5A adapter
1 × USB cable
1 × manual
1 × 12V / 1.5A adapter
1 × USB cable
1 × manual
