ISDT K4 AC 400W DC 600Wx2 Dual Mode Dual Channel Smart Charger For Lithium Battery

Part No.:	ISDT-K4
Manufacturer:	ISDT

Send to a friend

Features

- Independent dual channel｜Support 1~8S lithium battery｜20A ×2｜600W ×2
- AC/DC dual mode
- The output power in AC mode is 400W, and the output power in DC mode is 600W x2.
- You can choose AC input or DC input to meet the needs of different scenarios.

Product Details

Model No: K4
Input voltage: AC 100~240V / DC 10~34V
Output voltage: DC 1~34V
Max. input current: DC 45A
Max. charging power: AC 400W / DC 600W ×2
Max. Discharging power: 30W ×2
Parallel charging power/current: 800W/35A
Parallel discharging power/current: 60W/3A
Supported battery types and cell count: LiFe,LiIon,LiPo 1~8S；LiHv,ULiHv 1~7S; Pb 1~14S; NiMH/Cd 1~18S
Charging current: 0.2~20.0A ×2
Discharging current: 0.2~3.0A ×2
Balance current: 1.5A/Cell Max
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Support Working temperature: 0~40℃
Storage temperature: -20~60℃
Dimension: 176×183×57mm
Weight: About 1230g
