iFlight New BLITZ Mini F745 STM32F745 Flight Controller with Ardupilot Betaflight firmware for FPV Racing Freestyle Long Range
| Part No.: | IF-Mini-F745 |
| Manufacturer: | IFlight |
Send to a friend
Features
*Improved circuit design, better components, and lower electrical noise!
*Support Betaflight, INAV, Ardupilot firmware
*FC indicator LEDs for visual debugging
*DJI HD VTX Connector (Plug-and-Play / No soldering required)
*Support Betaflight, INAV, Ardupilot firmware
*FC indicator LEDs for visual debugging
*DJI HD VTX Connector (Plug-and-Play / No soldering required)
Product Details
MCU: STM32F745
Gyro: ICM42688
Barometer: DPS310
OSD Chip: AT7456E
Flash: 16MB (Blackbox flash)
UARTS: 6
Motor outputs: 4x (SH1.0 connector)
Smartaudio / IRC Tramp VTX protocol supported
LED controller: Yes
Beeper pad: Yes
Mount pattern: 20*20mm/φ4
Dimensions: 30.5*27 mm
Weight: 4.8g
BEC: Output 5V 2.5A continuous output current, 3A peak current (15 seconds)
BF Firmware target: IFLIGHT_BLITZ_F7_AIO
Ardupilot Firmware: arduplane_with_bl
Gyro: ICM42688
Barometer: DPS310
OSD Chip: AT7456E
Flash: 16MB (Blackbox flash)
UARTS: 6
Motor outputs: 4x (SH1.0 connector)
Smartaudio / IRC Tramp VTX protocol supported
LED controller: Yes
Beeper pad: Yes
Mount pattern: 20*20mm/φ4
Dimensions: 30.5*27 mm
Weight: 4.8g
BEC: Output 5V 2.5A continuous output current, 3A peak current (15 seconds)
BF Firmware target: IFLIGHT_BLITZ_F7_AIO
Ardupilot Firmware: arduplane_with_bl
Item Packing
1 x BLITZ Mini F745 Flight Controller
Detailed Images
