YIPINSERVO G25 25KG PWM Digital Coreless Servo Motor Full Metal Gear Large Torque Low Profile Short Body Servo for Rc Car 1/8 1/10

YIPINSERVO G25 25KG PWM Digital Coreless Servo Motor Full Metal Gear Large Torque Low Profile Short Body Servo for Rc Car 1/8 1/10
Part No.: G25-25kg
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

* Functional: The servo features anti-block and burn-out protection.
*Advanced Potentiometer: Includes a high-performance potentiometer for precise control.
*Waterproof: It offers excellent waterproofing to withstand harsh conditions.
*High Quality: Imported 7*11*3 and 6*10*3 bearings increase longevity and accuracy.It comes with a CNC aviation aluminum alloy shell and full steel gears, which resist wear and tear, and prevent teeth shredding.

Product Details

Number of teeth: 25T
Rotation angle: 180° or customized within 270 degrees
Dead zone: 2μs
Operating frequency: 1520μs / 330hz
Motor: High-performance coreless motor
Speed (6V): 0.08sec/60°
Speed (7.4V): 0.07sec/60°
Speed(8.4V): 0.06 sec/60°
· Stalled rotor torque (6V): 22kg.cm
· Stalled rotor torque (7.4V): 25kg.cm
· Stalled rotor torque (8.4V):27kg. cm
Size:41X20X28.5mm/1.614X0.79X1.22in
Weight: 68g
Connecting cable: JR 300 mm
Bearing: Imported 2BB
- CNC aviation aluminum alloy shell
- Gear: all steel teeth
- Potentiometer: high-performance potentiometer

Item Packing

1 X Yipinservo G25 Coreless Servo
1 X Set of Servo Accessories (includes spare gears and shaft pin)
1 X 25T Metal Servo Arm
