PM3505 GB3505 Brushless DC DD Motor Outer Rotor 12mm Center Hole Slip Ring

PM3505 GB3505 Brushless DC DD Motor Outer Rotor 12mm Center Hole Slip Ring
Part No.: PM3505-W
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

*No mechanical commutator, direct drive motor.
*Flat design, small size, light weight, high power density.
*It can be compatible with all kinds of encoders.
*It can output high torque at low speed.
*Hollow design, easy to thread and conductive slip ring.
*Multi slot flat stator design, smaller slot fluctuation, high efficiency.
*High performance NdFeB permanent magnet with small air gap and high torque.
*SH/UH high temperature resistant grade, no fear of demagnetization, strong overload capacity.
*Fully enclosed structure can prevent dust from entering into the motor, with high reliability.

Product Details

Item Name: PM3505
Nominal Voltage: 12 V
Nominal Current: 0.79 A
Nominal Torque: 0.07 N.M
Nominal Speed: 587 rpm
Max Speed: 890 rpm
Stall Torque: 0.11 N.M
Stall Current: 1.20 A
Winding turns of motor: 40 T
Phase to Phase Resistance: 6.5 Ω
Phase to Phase Inductance: 2.35 mH
Speed Constant: 74 rpm/V
Torque Constant: 0.09 N.M/A
Rotor Inertia: 56 gcm^2
Number of Pole Pairs: 11
Motor Weight: 42 g
Working Temperature: -20°C ~ 80°C
Max Demagnetize Temperature: 120°C

Item Packing

1× PM3505 Brushless Motor without encoder
