F540 Brushless Waterproof Motor 3300KV For 1/10 1/12 Rc Crawler Off Road Car

F540 Brushless Waterproof Motor 3300KV For 1/10 1/12 Rc Crawler Off Road Car
Part No.: F540-3300KV
Manufacturer: Feixiang

Send to a friend

Your name:
Your e-mail:
Recipient's email:

Features

- 4 poles with 12 slots design provides high torque and efficiency.
- High quality material is durable and eco-friendly.
- Precision engineered for maximum power conversion.
- Precision balanced rotor has high smoothness for best reliability and maximum RPM.
- Copper windings with high purity can maximizes efficiency.
- Compatible with 1 / 12 series models of most brands in the market and some 1 / 10 lightweight vehicles

Product Details

Material: Metal
KV(RPM/Volt):3300KV
Watts: 800W
Max voltage: <17V
Max Amps: 47A
Rotor Poles:4
IO: 1.9A
Resistance: 0.0285
Max RPM: 50000
Length: 50mm
Diameter: 36mm with fins
Weight: 147g
Shaft diameter: 3.175mm
Length of extend shaft:15mm
Plug type: 4mm golden banana plug

Item Packing

F540 3300KV Motor x 1
